Multi Core SM Strength Member Fiber Optic Cable Non Metallic For Aerial / Duct
| Place of Origin | Dong Guan China |
|---|---|
| Brand Name | MingTong |
| Certification | ISO |
| Minimum Order Quantity | 20km |
| Price | 500-5000RNB/KM |
| Packaging Details | Wooden scroll + cardboard box / Wooden scroll + wooden board |
| Delivery Time | It depends on the actual situation. |
| Payment Terms | L/C,T/T |
| Supply Ability | 200km/Day |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Strength Member Fiber Optic Cable | Loose Tube Material | PBT Or Jelly |
|---|---|---|---|
| Outer Sheath Material | PE | Single Armour Material | Corrugated Aluminium Tape |
| Outer Sheath Color | Black | Waterblocking Material | Water Blocking Tape Or Filling Compound |
| Highlight | Double Armoured Optic Fiber Cable, GYTA53 Armoured Optic Fiber Cable, Armoured GYTA53 Fiber Optic Cable | Fiber Count | 2-144 Core |
| Highlight | SM Strength Member Fiber Optic Cable,Aerial Strength Member Fiber Optic Cable,Duct Non Metallic Fiber Optic Cable |
||
Product Description
Product Description
Outdoor Non-Metallic Mutil-Core Sm Strength Member Fiber Optical Cable
This Outdoor Double Armoured Optic Fiber Cable are suitable for installation in harsh environments where mechanical impact on the cable is to be expected. E. G. Direct buried opplication. Outdoor Double Armoured Optic Fiber Cable are also suitable for installation in ducts where the rodent resistance is to be expected or the moisture resistance is expected.
Features
1.Excellent optical, mechanical & environmental performance
2.Moisture-proof & roden-proof
3.High strength-to-weight ratio
4.High tensile strength
5.High crush strength
6.Corrosion resistance
7.Very flexible bending radius
Application
1.Aerial / Duct
2.Connecting communication equipments
3.Multi-cores wiring system in data center
Technical data
| Fiber Num. | Outer diameter (mm) | Weight (kg/km) | Min.Bending radius(mm) | Tension (N) | Crash loading (N/100mm) | |||
| Static | Dynamic | Short term | Long term | Short term | Long term | |||
| 2-24 | 12.6 | 185 | 12.5 times O.D. | 25 times O.D. | 3000 | 1000 | 3000 | 1000 |
| 26-36 | 12.9 | 195 | ||||||
| 38-60 | 13.4 | 200 | ||||||
| 62-72 | 13.9 | 230 | ||||||
| 74-96 | 15.5 | 275 | ||||||
| 98-120 | 17 | 320 | ||||||
| 122-144 | 18.4 | 365 | ||||||
| 146-216 | 18.9 | 385 | ||||||
| 218-240 | 22.1 | 495 | ||||||
| 242-288 | 24.3 | 580 | ||||||
