Black Central Loose Tube Cable Figure 8 Self Support Fiber Optic Cable GYXTC8S GYXTC8A
| Place of Origin | Dongguan CHINA |
|---|---|
| Brand Name | MingTong |
| Certification | ISO |
| Minimum Order Quantity | 20km |
| Price | 500-3000RNB/KM |
| Packaging Details | Wooden scroll + cardboard box / Wooden scroll + wooden board |
| Delivery Time | It depends on the actual situation |
| Payment Terms | L/C,T/T |
| Supply Ability | 200km/Day |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Central Loose Tube Cable | Structure Section | "8" Figure Cross Section |
|---|---|---|---|
| Brand Name Of Fiber | Corning, Yofc, Draka, Fujikura | Outer Sheath Material | MDPE / HDPE |
| Outer Sheath Color | Black | Loose Tube Material | PBT Or Jelly |
| Single Armour Material | Corrugated Aluminium Tape | Waterblocking Material | Water Blocking Tape Or Filling Compound |
| Installation Methods | Self-Support Aerial | Operating Temperature | -40 Degree ~ +60 Degree |
| Highlight | Outdoor Fiber Optic Cable GYXTC8S, Outdoor Fiber Optic Cable GYXTC8A, GYXTC8A Self Support Optic Cable | ||
| Highlight | Self Support Fiber Optic Cable GYXTC8A,Self Support Fiber Optic Cable GYXTC8S,Black Central Loose Tube Cable |
||
Product Description
central loose tube figure 8 self-support fiber optic cable GYXTC8S/GYXTC8A
Product Description
This GYXTC8S Outdoor Self-support 12 Core Fiber Optic Cable has been designed for long haul / backbone application. GYXTC8S Outdoor Self-support 12 Core Fiber Optic Cable are designed for easy and economical installation.
GYXTC8S Outdoor Self-support Multimode Optic Fiber Cable Structure &Properties:
1. Up to 24 fibers The loose tube OS centrally situated with good excess length and minimizes the influence of lateral crush.
2. Water blocking tape armored and PE outer sheath prociding providing property crush resistance and gun shot resistance features.
3. Cross-section shows figure 8. Stranded wires as self supporting member providing excellent strain performance and convenient installation.
GYXTC8S Outdoor Self-support 12 Core Fiber Optic Cable Applicable Fields:
This cable has been designed for aerial application with messenger wire as support member made excellent anti-pull performance and easy installation.
GYXTC8S Outdoor Self-support 12 Core Fiber Optic Cable Technical Date:
Technical data: |
||||||||||||
| Fiber core | Stranded Wire | Cable diameter (mm) | Messenger cable Diameter (mm) | Cable Height (mm) | Cable weight (kg/kg) | Min.bend radius | Max. Running tension (N) | Safe running tension (N) | Min.Breaking tension (N) | Max.crush loading (N/100mm) | ||
| Dynamic | Static | Short term | Long term | |||||||||
| 2-12 | 1×7-3.0 | 8.3 | 5.0 | 15.8 | 135 | 10D | 20D | 3000 | 1000 | 7990 | 2000 | 1000 |
