216 Core Outdoor Rated Fiber Optic Cable Single Mode Armored OM3 Fiber Optic Cable GYTS
| Place of Origin | Dongguan CHINA |
|---|---|
| Brand Name | MingTong |
| Certification | ISO |
| Minimum Order Quantity | 20km |
| Price | 500-3000RNB/KM |
| Packaging Details | Wooden scroll + cardboard box / Wooden scroll + wooden board |
| Delivery Time | It depends on the actual situation |
| Payment Terms | L/C,T/T |
| Supply Ability | 200km/Day |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Outdoor Rated Fiber Optic Cable | Type | Single Mode &Multi Mode |
|---|---|---|---|
| Fiber Range | 2-288 | Fiber Color | Blue,Orange,Brown,Aqua,Grey |
| Structure | Loose Tube | Color | Black |
| Jacket Material | PE | OEM | Available |
| Max.crush Loading Force | 1000N/100mm | Application | Telecommunication |
| Operating Temperature | -40 ~ +60 C | Highlight | 216 Core Outdoor Rated Fiber Optic Cable, Om Outdoor Rated Fiber Optic Cable, Om3 Fiber Optic Cable Gyts |
| Highlight | Outdoor Rated Fiber Optic Cable Single Mode,OM3 Fiber Optic Cable GYTS,GYTS Fiber Optic Cable |
||
Product Description
GYTS 216 Core Om3 Outdoor Rated Fiber Optic Cable
Specification
· OEM 2-288 Core Optical Fiber Cable
· Cutomer LOGO
· Factory price
· 3 days delivery time
· 25 years quality guaranteed
GYTS Fiber Optic Cable Details
1.OEM fiber optic cable manufacturer.
2. Fiber brand : YOFC, CORNING,FUJIKURA.
3.Quality certification :ISO9001.ROSH.REACH.
4.Cooperate with Vietnam telecom, Thai telecom, Singapore telecom, Dubai telecom and other big projects.
5.Tw-scie known as the fiber optic cable manufacturer for the excellent products quality, competitive prices , fast delivery and good service.
Main Export Markets
· Central/South America
· Mid East/Africa
· Eastern Europe
· North America
· Asia
· Western Europe
· Australasia
GYFTY optic fiber cable Technology Specification
| GYFTY Fiber Optic Cable Technology Specification | |||||||||
| Cable Count | Out sheath | Weight | Minimum allowable Tensile Strength | minimum allowable Crush Load | Minimum Bending Radius | Storage | |||
| Diameter | (N) | (N/100mm) | (MM) | temperature | |||||
| (MM) | (KG) | short term | long term | short term | long term | short term | long term | (°C) | |
| 2-60 | 9.8 | 65 | 1500 | 600 | 1000 | 300 | 20D | 10D | -40+60 |
| 62-72 | 10.5 | 85 | 1500 | 600 | 1000 | 300 | 20D | 10D | -40+60 |
| 74-96 | 14.5 | 145 | 1500 | 600 | 1000 | 300 | 20D | 10D | -40+60 |
| 98-144 | 18.3 | 185 | 1500 | 600 | 1000 | 300 | 20D | 10D | -40+60 |
| GYFTY optic fiber cable Optical Characteristics | ||||
| Fiber Sort | Multimode | G.651 | A1a:50/125 | Graded-index fiber |
| A1b:62.5/125 | ||||
| Singlemode | G.652(A,B,C) | B1.1:Conventional fiber | ||
| G.652D | B2: Zero dispersion shifted | |||
| G.655 | B1.2 :Cut-off wavelength shifted | |||
| G.657(A1,A2 ,B3) | B4: Main technical data for positive | |||
| dispersion shifted single-mode fiber |
||||
