GYTA53 Direct Burial Fiber Optic Cable Loose Tube Stranded 12 Core Armoured Fiber Optic Cable
| Place of Origin | Dongguan CHINA |
|---|---|
| Brand Name | MingTong |
| Certification | ISO |
| Minimum Order Quantity | 20km |
| Price | 500-3000RNB/KM |
| Packaging Details | Wooden scroll + cardboard box / Wooden scroll + wooden board |
| Delivery Time | It depends on the actual situation |
| Payment Terms | L/C,T/T |
| Supply Ability | 200km/Day |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Application | Telecommunication,Aerial, Duct | Name | Direct Burial Fiber Optic Cable Loose Tube |
|---|---|---|---|
| Fiber Type | G652D,single Mode Or Multi Mode | Fiber Count | 2/4/6/8/12 Core |
| Color | Black,Customized | Jacket | PE,MDPE,LSZH |
| Product Name | Outdoor Optic Fiber Cable | Length | 1 Km 2km 3km Per Drum |
| Oem | Available | Structure | Loose Tube |
| Operating Temperature | -40~75 | Strength Member | Two Steel Wire |
| Fiber Color | Blue,Orange,Brown,Grey | Core | Up To 48 Fibers |
| Highlight | GYTA53 Armoured Fiber Cable, Loose Tube Armoured Fiber Cable, Direct Burial Armoured Ofc Cable | ||
| Highlight | GYTA53 Direct Burial Fiber Optic Cable,Direct Burial Fiber Optic Cable Loose Tube,12 Core Armoured Fiber Optic Cable |
||
Product Description
GYTA53 Direct Burial Outdoor Loose Tube Stranded Armoured Multi Core Fiber Optical Cable Price
Cable Description:
Loose tube cable is a design that has high tensile strength and flexibility in a compact cable size. Our loose tube cable provides excellent optical transmission and physical performance.
Feature
Overlapping aluminium tape providing an excellent anti-moisture performance
Double sheath
GYTA53 optic fiber cable Applications:
1.Adopted to Outdoor distribution
2.Suitable for duct and buried method
3.Long distance and local area network communication
4.Used OUTDOOR cabling
| GYTA53 Fiber Optic Cable Technology Specification: | |||||||||
| Out sheath | Tight buffer | Weight | Minimum allowable | Minimum allowable Crush Load | Minimum Bending Radius | Storage | |||
| Diameter | Diameter | TensileStrength(N) |
(N/100mm) | (MM) | temperature(°C) | ||||
| (MM) | (MM) | (KG) | short term | long Term | short term | long term | short term | long term | -40+60 |
| 2-60 | 13.3 | 2210 | 3000 | 1000 | 3000 | 1000 | 20D | 10D | -40+60 |
| 62-72 | 14.6 | 255 | 3000 | 1000 | 3000 | 1000 | 20D | 10D | -40+60 |
| 74-96 | 16.2 | 305 | 3000 | 1000 | 3000 | 1000 | 20D | 10D | -40+60 |
| 98-120 | 17.7 | 350 | 3000 | 1000 | 3000 | 1000 | 20D | 10D | -40+60 |
| 122-216 | 19.6 | 420 | 3000 | 1000 | 3000 | 1000 | 20D | 10D | -40+60 |
| GYTA53 Fiber Optic Cable Characteristics: | ||||
| Fiber Sort | Multimode | G.651 | A1a:50/125 | Graded-index fiber |
| A1b:62.5/125 | ||||
| Singlemode | G.652(A,B,C) | B1.1:Conventional fiber | ||
| G.652D | B2: Zero dispersion shifted | |||
| G.655 | B1.2 :Cut-off wavelength shifted | |||
| G.657(A1,A2 ,B3) | B4: Main technical data for positive | |||
| dispersion shifted single-mode fiber | ||||
Competitive Advantages:
1.OEM fiber optic cable manufacturer .
2. Fiber brand : YOFC, CORNING,FUJIKURA .
3.Quality certification :ISO9001.ROSH.REACH.
4.Cooperate with Vietnam telecom, Thai telecom, Singapore telecom, Dubai telecom and other big projects.
5.Tw-scie known as the fiber optic cable manufacturer for the excellent products quality,competitive prices , fast delivery and good service.
Why choose us?
1.Introduction of foreign advanced production equipment and technology, have 12 year production experience, 80% employees have more than 10 years experience, excellent enterprise culture and management team.
2.FAST SHIPPING from factory
3.Item shipped in 3-15 working days after payment is received depends on the quantity of the order.
4.We accept T/T, L/C, Western Union, Money Gram and Paypal, just choose what you like.
5.We accept OEM. The cable size and material are customized. Your own logo and own design are welcome. We will produce according to ur requirement and description;
6.With more than 12 years experience in fiber optic cable,we already cooperated and established long-term business relationship with both domestic and overseas famous enterprise
