Good In Exchange Fiber Optic Patch Cord SM MM Fiber Pigtail Connector LC / UPC
| Place of Origin | Dongguan CHINA |
|---|---|
| Brand Name | MingTong |
| Certification | ISO |
| Minimum Order Quantity | 200 |
| Price | 5-200RNB/P |
| Packaging Details | cardboard box |
| Delivery Time | It depends on the actual situation |
| Payment Terms | L/C,T/T |
| Supply Ability | 2000 copies/Day |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Fiber Optic Patch Cord | Polish | UPC,APC |
|---|---|---|---|
| Fiber Type | SM/MM | Connector | SC,FC,LC,ST,MU,DIN,MTRJ,E2000,MPO |
| Cord Type | Simplex ,Duplex | Cable Jacket | PVC,LSZH,OFNR,OFNP |
| Highlight | Pigtail Fiber Optic Cable, Ofc Pigtail | ||
| Highlight | Fiber Optic Patch Cord SM,LC UPC Pigtail Fiber Optic Cable,Fiber Pigtail Connector |
||
Product Description
LC/UPC Fiber Optic Pigtail
The LC pigtail fiber optic cable has connectors on one end for fast and easy connection to CATV, optical switches, or other telecom equipment. It's available in single mode and multimode versions, and features an LC connector with a zirconia ceramic ferrule, pre-polished PC profile, and convex spherical end.
By allowing for faster polishing, low back reflection, and optical loss, these end-face types ensure maximum repeatability.
Features
Low insertion loss and back reflection loss
Ferrule end surface is pre-domed
Excellent mechanical endurance
Good in repeatability
Good in exchange
Applications
Telecommunications
CATV, LAN, MAN, WAN, Test & Measurement
Military industry
Medical
Parameter
| Parameter | Unit | Standard & Requirement | |||||
| PC(SM) | UPC(SM) | APC(SM) | PC(MM) | ||||
| Insertion Loss (Typical) | dB | ≤0.3 | ≤0.3 | ≤0.2 | ≤0.2 | ||
| Return Loss | dB | ≥45 | ≥50 | ≥60 | ≥35 | ||
| Mechanical Endurance (500T) | dB | ≤0.2 | |||||
| Exchangeability | dB | ≤0.2 | |||||
| Durability | Time | ＞500 | |||||
| Vibration | dB | ≤0.2 | |||||
| Operating Temperature | ℃ | ﹣40 ～﹢75 | |||||
| Storage Temperature | ℃ | ﹣45 ～﹢85 | |||||
| Cable Diameter | mm | Ф2.0mm± 2% | |||||
FIBER CHARACTERISTICS
| ITEM | CONSTRUCTION | ||||
| FIBER TYPE | Single mode: G652, Multimode: G651 | ||||
| MODE | FIELD | DIAMETER | |||
| @1310NM | 9.0±0.5μm | ||||
| CLADDING DIAMETER | 125±1μm | ||||
| CORE | CONCENTRICITY | 0.6μm | |||
| ERROR | |||||
| ≦ | |||||
| CLADDING | 1.0% | ||||
| NON-CIRCULARITY | |||||
| ≦ | |||||
| PRIMARY | COATING | ||||
| DIAMETER | 250±15μm | ||||
| COATING-CLADDING | |||||
| CONCENTRICITY ERROR | ≦12.5μm | ||||
| FIBER CURL RADIUS | 4m | ||||
| ≧ | |||||
| LSZH or better (OFNR-rated). The non-circular < 2%. Yellow color. printed cables | |||||
| Casing | information, type, length, | ||||
| The bend R | 3 cm | ||||
| Installation: ≥ 200 N | |||||
| Greatest tension | Operating: ≥ 200 N | ||||
| The force mashed | 550 N/cm | ||||
